PW Automatic Laser Tailor Welding Machine
PW Series

Product Data

Features:

●  Consist of welding part, steel sheet position structure, sheet dragging structure and automatic feeding robot hand

●  Each axis is transmitted by high precision pinion and rack and ball screw

●  High efficiency transmission

●  Equipped with weld tracking system to make effective compensation for weld excursion

●  Equipped with high precision magnetic separator to ensure transmitting one steel sheet at a time

●  Especially for tailor-welding cold-roll steel sheets and hot galvanized steel sheets

X-axis Stroke

2100mm

Y-axis Stroke

20mm

Z-axis Stroke

100mm

Position Structure Stroke

150mm

Positioning Accuracy

0.08/1000mm

Repeated Positioning Accuracy

0.05mm

Moving Speed

30m/min

Laser Source Power

3000-6000W

Focal Length

250-300mm

Steel Sheet Thickness

0.6-3mm

Steel Sheet Width

250-2000mm

Steel Sheet Length

600-3000mm

Welding Speed

5000-10000mm/min

Welding Flatness

≤0.10mm/m

Welding Straightness

≤0.15mm/m

Machine Size

11715*9320*3285mm

Weight

25000kg

CNC System

SIEMENS 840DSL

Capacity

80KVA

Phase

3

Voltage

380V

Frequency

50Hz

Protection Grade

IP54
